| Product Line | Suspension |
| Category Name | Air Springs and Bags |
| Part Type | Double Convoluted Air Spring |
| Alternate Part Name | Double Convoluted Air Spring, Double Convolution Air Bag, Double Bellow Air Spring, Heavy Duty Suspension Air Bag, Trailer Suspension Air Spring, Rubber Bellows Air Suspension Bag |
| OEM Part Number | W01-358-6945 |
| Application Type | Heavy Duty Trucks, Semi-Trucks |
| VMRS Code | 016-008-000 |
| Material | Fiber reinforced rubber bellows |
| Body Diameter | 8.88 in. |
| Bottom Mounting Stud Size | 3/8-16 NPTF |
| Bottom Plate Alignment | 90 deg. |
| Bottom Plate C To C Diameter | 3.50 in. |
| Bottom Plate Diameter | 6.40 in. |
| Bottom Plate Hole Size | 1/2-13 UNC |
| Bottom Plate Tapped Hole Qty | 2 |
| Top Plate Air Inlet | 1/4-18 NPTF |
| Top Plate C To C Diameter | 3.50 in. |
| Top Plate Diameter | 6.40 in. |
| Top Plate Stud Qty | 2 |
| Top Plate Stud Thread Size | 1/2-13 UNC |
| Air Spring Type | Double Convoluted |
| Collapsed Length | 4.10 in. |
| Extended Length | 13.50 in. |
| Net Weight | 9.88 lb. |
| Cross References | 1003586945C, 2B09253, 2B9253, 3546945, 4427, 566CT64550, 57006945, 64550, 6945, ABSP2B12RA6945, AS0119F, AS01451G, CS209253, FAS-0603, FAS0603, FD20025427, FS6945, W013586945, W01-358-6945 |
| Intended Application | - For lift axle suspensions in heavy-duty trucks and trailers.
|
